Description CS62 2-port KVM Switch has a handy design integrating with 1.2m of cable. It can control 2 servers via a single console FeaturesSpecificationsDiagramPackage Contents One PS/2 console controls 2 PS/2 computers Compact design,built in 1.2m cables All-in-one design Superior video quality-up to 2048 x 1536; DDC2B Auto Scan function to monitor computer operation Non-powered OS Compatibility includes Windows 2000/XP/Vista, LINUX and FreeBSD Computer Connections 2 Port Selection Hotkey Connectors Console Ports Keyboard 1 x 6-pin Min-DIN Female (Purple) Video 1 x HDB-15 Female (Blue) Mouse 1 x 6-pin Min-DIN Female (Green) Speakers N/A Microphone N/A KVM Ports Keyboard 2 x 6-pin Min-DIN Male (Purple) Video 2 x HDB-15 Male (Blue) Mouse 2 x 6-pin Min-DIN Male (Green) Speakers N/A Microphone N/A LEDs Selected 2 (Green) Cable Length Computers 1.2 m Emulation Keyboard/Mouse PS/2 Video 2048 x 1536; DDC2B Scan Interval 3, 5, 10, 20 seconds Environment Operating Temp. 0°C~50°C Storage Temp. -20°C~60°C Humidity 0~80% RH, Non-condensing Physical Properties Housing Plastic Weight 0.33 kg Dimensions ( L x W x H ) 7.30×6.24×2.25cm 1x 2-Port Petite KVM Switch with Attached Cables 1x User Instructions
